Specification
| Size | 1/2“，3/4”，1“，1.5”，2“，2.5” |
| Material | SS304 or SS316L |
| Diaphragm material | Epdm rubber, Silicone rubber, EPDM rubber + PTFE |
| Working | Manual Or Pneumatic (including normally open and normally closed designs) |
| Connection type | Welding, Clamping, Threading |
| Body construction | Straight, Three-way, U |
| Working temperature | EPDM：（-40℃〜150℃）EPDM + PTFE：（-10℃〜150℃） |
| Working pressure | 10 bar |
