Specification
| Product name | Pneumatic Diaphragm Valve Clamp End |
| Size | DN20~DN50 |
| Body material | CF3M, 316L |
| Sealing material | EPDM ,EPDM+PTFE |
| Working pressure | 0-0.8MPa |
| Wrking temperature | -20℃~150℃ |
| Connection way | Clamp, Weld, Thread, Flange |
| Standard | GB, ASME BPE, ISO, DIN, SMS |
| Surface finish | SF1-SF6(ASME BPE2007) |
