Specification size 3/4“ to 12"(DN20 to DN300) Rated Working Pressure 350 psi(25 bar) Sch10S,cut groove piping only Housings Type 304 Stainless Steel to ASTM A351 CF8 or A743 Gr.CF8 Rubber Gaskets The
size |
3/4“ to 12"(DN20 to DN300) |
Rated Working Pressure |
350 psi(25 bar) Sch10S,cut groove piping only |
Housings |
Type 304 Stainless Steel to ASTM A351 CF8 or A743 Gr.CF8 |
Rubber Gaskets |
The structural form of the sealing ring adopts a "C" type sealing structure, and the material is EPDM. The operating temperature range is (-50 to 150℃). Suitable for cold water, hot water, dilute acid, oil-free air and various chemicals; Not suitable for petroleum-based media. |
Bolt&Nuts |
Type 304 Stainless Steel Track Bolts and Nuts to ASTM F-593 |
